ALPINE UTE-200BT

Max Power Output Ratings

• Max Power Output: 4 x 50W

FM Tuner

• Tuning Range: 87.5 - 108.0 MHz
• Alternate Channel Selectivity: 75 dB
• Signal-to-Noise Ratio: 73 dB
• Stereo Separation: 50 dB

MW Tuner

• Tuning Range: 531 - 1,602 kHz
• Usable Sensitivity (IEC Standard): 26 ( μV/dB)

LW Tuner

• Tuning Range: 153 - 281 kHz
• Usable Sensitivity (IEC Standard): 50 ( μV/dB)

USB

• USB Requirements: USB full-speed
• Max. Power Consumption: 1,000 mA
• USB Class: Mass Storage Class
• File System: FAT 12/16/32
• Flac Decoding: Free Lossless Audio Codec Format
• MP3 Decoding: MPEG Audio Layer-3
• WMA Decoding: Windows Media™ Audio
• AAC Decoding: AAC-LC Format ′′.m4a′′ File

BLUETOOTH®

• BLUETOOTH® Version : Bluetooth v3
• Output Power: +4 dBm Max. (Power Class 2)
• HFP: Hands Free Profile
• A2DP: Advanced Audio Distribution Profile
• AVRCP: Audio/Video Remote Control Profile v1.3
• PBAP (Phone Book Access Profile)
• SPP (Secure Simple Pairing)

Sound Tuning

• Subwoofer Level Adjustment: 0 to 15 dB
• Subwoofer Phase Setting: 0° or 180°
• BASS ENGINE SQ: Level 0 - 6
• Bass Level Control Range: ±9.1 dB at 100Hz
• Treble Level Control Range: ±9.1 dB at 10 kHz
• Parametric Equalizer (Band 1): 20 - 100 Hz
• Parametric Equalizer (Band 2): 63 - 315 Hz
• Parametric Equalizer (Band 3): 125 - 500 Hz
• Parametric Equalizer (Band 4): 250 - 1k Hz
• Parametric Equalizer (Band 5): 500 - 2k Hz
• Parametric Equalizer (Band 6): 1k - 4k Hz
• Parametric Equalizer (Band 7): 2k - 7.2k Hz
• Parametric Equalizer (Band 8): 5.8k - 12k Hz
• Parametric Equalizer (Band 9): 9k - 20k Hz
• Parametric Equalizer (Gain): -7 to 0 +7
• Parametric Equalizer (Bandwidth): 3, 4, 5
• 2Way Crossove Mode: Cut-off Frequency 20-200Hz, Slope Flat/6/12/18/24 dB/oct, Level -12 to 0dB
• 3Way Crossover Mode: Cut-off Frequency Low/Mid Low 20-800Hz Mid High 20-20kHz High 1k-20kHz, Slope Flat/6/12/18/24 dB/oct, Level -12 to 0dB
• Application Volume Level Setting: ±14 dB

General

• Power Requirement: 14.4 V.DC (11-16V allowable)
• Pre Output Voltage (Before Clipping): 2V / 10k ohms
• Aux In: 1.4V / 10k ohms
• Maximum Mounting Angle: 35°
• Weight: 1.4 kg

Dimensions

• Din Size: 1 DIN
• Chassis Size (W x H x D) mm: 178 x 50 x 161.5 mm
• Nose Piece Size (W x H x D) mm: 170 x 46 x 25 mm
